Description
| System Hardware | |
|---|---|
| CPU | Intel® Processor Core™ 12th Gen i3/i5/i7 |
| Watchdog | 0–255 seconds / grading implemented through system software |
| Memory | DDR4 (optional 8/16/32/64GB, max 16GB for N97) |
| Storage | M.2 2280 NVME SSD (optional 128/256/512GB/1T/2T/4T) |
| Display | |
|---|---|
| LCD Type | 12.1″ |
| Touchscreen Type | 1280×800 |
| Max Resolution | 12.1″ Multi point capacitive touch screen |
| Luminance | 300 cd/m² |
| Contrast Ratio | 1000:1 |
| OS | |
|---|---|
| OS | Windows 10/11, Ubuntu |
| I/O Interface | |
|---|---|
| USB | 2×USB3.2, 2×USB2.0 (optional USB3.0) |
| Serial Port | 1×RS232; optional additional 3×RS232/485/422 on top (Max 2×RS485 or 1×RS485 + 1×RS422) |
| LAN | 2×1Gbe RJ45 (Realtek) |
| GPIO | Customizable 4in+4out+VCC+GND |
| Audio | 1×Line out, 1×MIC in |
| Video | 1×HDMI, 1×VGA |
| Expansion Slot | Optional dual band WIFI/BT, optional 4G/5G communication |
| Power | |
|---|---|
| Power Input | Standard Phoenix terminal (Optional Auto power on & 9–36V wide voltage input) |
| Environment | |
|---|---|
| Operating Temp. | 10~60°C, Surface air flow |
| Storage Temp. | -20~70°C |
| Humidity | 95% @40°C, no condensation |
| IP Rating | Front panel IP65 |
| Reliability | MTBF ≥30000h; MTTR ≤0.5h |
| Shock Protection | 10g acceleration, 11ms cycle |
| Vibration Protection | 5–17Hz/1.0mm amplitude; 17–200Hz/1.0g acceleration |
| Mechanical | |
|---|---|
| Dimension | 315.8mm × 218mm × 52.9mm |
| Weight | 3.5kg / 3.9kg (N.W./G.W.) |
| Color | Black |
| Material | All metal fanless design |
| Mounting | VESA Installation: 75×75mm / 100×100mm; Embedded Installation: 302.10mm × 204.30mm |
