Description
| System Hardware | |
|---|---|
| CPU | Rockchip RK3568 |
| Watchdog | Support hardware reset function (256 levels, 0~255 seconds) |
| Memory | 4GB LPDDR4 |
| Storage | EMMC 32GB, optional 16G |
| Display | |
| LCD Type | 10.1″ LCD |
| Touchscreen Type | 10.1″ capacitive touch screen |
| Max. Resolution | 1280×800 |
| Luminance | 350 cd/m² |
| Contrast Ratio | 800:1 |
| OS | |
| OS | Android 11.0 |
| I/O Interface | |
| USB | 2×USB 3.0 |
| Serial Port | 1×RS232, 1×TTL |
| LAN | 1×1000M network interface |
| TF | 1×TF |
| Audio | 3.5mm audio interface (2-in-1) with built-in speaker |
| Video | 1×HD |
| Power | |
| Power Supply | 12V DC input (12/5A power adapter; 9–36V DC optional) |
| Environment | |
| Operating Temp. | -10~60°C, without air flow |
| Storage Temp. | -20~70°C |
| Humidity | 95% @40°C, non-condensing |
| IP Rating | IP54 |
| Reliability | MTBF≥30000h; MTTR≤0.5h |
| Shock Protection | 10g / 11ms |
| Vibration Protection | 5–19Hz / 1.0mm amplitude; 19–200Hz / 1.0g acceleration |
| Mechanical | |
| Dimension | 290×210×42.4mm |
| Weight | 1.70kg / 2.10kg (N.W./G.W.) |
| Color | Black |
| Material | Aluminum alloy panel, all-metal fanless design |
| Mounting | VESA mounting: 100×100mm; Embedded installation: 272.4×193.8mm |
