Description
| System Hardware | |
|---|---|
| CPU | Intel® Elkhart Lake™ 11th Celeron® J6412 |
| Memory | 1×DDR4 SO-DIMM memory slot, supporting up to 32GB |
| Storage | 1×M.2 2280 slot (SATA/NVMe PCIe x1, interface auto recognition) |
| Display | |
|---|---|
| LCD | 12″ LCD |
| Touchscreen | Capacitive touch screen |
| Max Resolution | 1920×1080 |
| Luminance | 450 cd/m² |
| Contrast Ratio | 800:1 |
| OS | |
|---|---|
| OS | Windows 10/11, Linux |
| I/O Interface | |
|---|---|
| USB | 4×USB3.0 (4×USB2.0 built-in) (USB3.0: 3.4 support 1.5A, 1.2 support 0.9A) |
| COM | COM1: 1×RS232/422/485 (jump cap optional, default RS232); COM2/3/4: 1 out 3 serial port cables (RS232 and 2×RS485 or 1 out 3 RS232, 485 jump cap options) |
| Audio | 1×4-section 3.5mm Audio Jack (supports headphone output and microphone input); 1×Horn 8Ω 3W |
| Video | 1×HD, 1×VGA pins customizable for export |
| DC Port | Phoenix terminal 3-pin |
| Mini PCIe | 1×Mini PCIe (WiFi+BT/4G/5G optional, one out of three) |
| SIM Card | 1×Built-in SIM card holder |
| GPIO | NA |
| LAN | 2×1000M LAN port |
| Power | |
|---|---|
| Power | 10–32V wide voltage input, standard with 12V/5A adapter |
| Environment | |
|---|---|
| Vibration Protection | 5–17Hz/1.0mm amplitude; 17–200Hz/1.0g acceleration |
| Shock Protection | 10g acceleration, 11ms cycle |
| IP Rating | Front panel IP65 |
| Operating Temp. | -10~55°C (wide temperature optional) |
| Storage Temp. | -30~70°C (wide temperature optional) |
| Humidity | 95% @40°C, non-condensing |
| Mechanical | |
|---|---|
| Dimension | 408 × 257.3 × 55.9 mm |
| Weight | 4.09 kg |
| Color | Silver |
| Material | Aluminum alloy |
| Mounting | VESA mounting: 100×100mm; Embedded installation: 396×245mm |
