Description
| Model | WMP 19J IP0A (STD) | WMP 19J IP0B (ISO) |
|---|---|---|
| Main System | ||
| CPU / Chipset | FCBGA1528 8th Gen Intel® Core i7/i5 processor (15W Max.), Optional vPro (i7/i5) / SoC | |
| Graphic | Intel® integrated UHD Graphics 620 | |
| RAM | Two DDR4 2400MHz SO-DIMM, non-ECC, up to 64GB | |
| OS Support | Optional Windows 10 IoT Enterprise | |
| Storage | 2.5” SSD/HDD M.2 SSD (M Key 2242/2260/2280), PCIe x4 & SATA3 |
|
| Expansion | 1 x PCIex4, 1 x M.2 E Key Optional: 802.11 ac/a/b/g/n WLAN + Bluetooth Module |
|
| Display Size | 19” TFT-Color LCD (5:4) | |
| Display | 1280 x 1024 (SXGA), 16.7M colors, 170(H)/160(V), 350 nits (Typ), CR: 1000:1 (Typ) | |
| Touch Screen | Full Flat Projected Capacitive Touch Panel Light Transmission: ≥87%, Hardness: 7H, Pressure: 765g/45°, Life: 50,000 times |
|
| I.O. Ports | ||
| USB | 4 x USB3.1 Gen II | 4 x USB3.1 Gen II, 1 x ISO USB2.0 |
| COM | 1 x RS232/422/485 1 x RS232 |
1 x RS232/422/485, 1 x RS232 1 x ISO RS232/422/RS485, 1 x ISO RS232 |
| LAN | Gigabit / 2 x RJ45 | Gigabit / 2 x RJ45, 1 x ISO RJ45 |
| Audio | 2 x 3.5mm phone jack (Line-out, Mic-In) | |
| Video Out | 1 x DP1.2, 1 x HDMI 1.4 | |
| Control Hot Key (R to L) | Power Button, Volume -, Volume +, Brightness -, Brightness +, LCD On/Off, Clean Me | |
| Mechanical and Environmental | ||
| Cooling | Fanless Design with External Heatsink | |
| Power Input | DC-In x 1, DC 12~24V input | |
| Power Adapter | AC input 100~240V / 47~63 Hz / DC output 18V, 100W (Universal Type) | |
| Temperature | Operating: 0~35℃ (Expansion Card 20W), 0~40℃ (Expansion Card 15W), 25W (by project) Storage: -20~60℃ |
|
| Humidity | Operating & Storage: 10~90%, non-condensing | |
| IP Rating / Housing | IP65 (Front), IPx1 Whole System Front: Full flat design / Touch (standard) / Glass (customized) Rear: Plastic White with Anti-bacteria (MRSA) Housing |
|
| Dimensions (Net) | 450 mm (H) x 420 mm (V) x 85.3 mm (T) | |
| Weights (Net) | 7.5 kg (w/o power adapter/battery pack) | |
| Mounting | Optional Stand, VESA 75/100 | |
| Certification | ||
| Compliance | CE: EN 60601-1-2:2015 (V4.0) EN 60601-1:2006 + A11:2011 + A1:2013 + A12:2014 (by project) VCCI: 2016-11, Class B (PSU with PSE, battery not included) FCC: Part 18 Class B UL: ANSI/AAMI EN60601-1:2012 (V3.1) (by project) cUL: CAN/CSA-C22.2 No. EN60601-1:2014 (V3.1) (by project) ISO 14971 / IEC62133 |
|
