Description
| Model | WMP 15P IP0A (STD) | WMP 15P IP0B (ISO) |
|---|---|---|
| Main System | ||
| CPU / Chipset | Intel® 13th Gen. Core i7/i5/i3 & Celeron (15W Max.) / SoC (FCBGA1744) | |
| Graphics | Intel® Iris Xe (i7/i5), Intel® UHD (i3) | |
| RAM | 2 x DDR5 SODIMM, 5200 MHz, Dual Channel, Non-ECC, up to 96GB | |
| OS Support | Windows 10 IoT Enterprise LTSC / Windows 11 IoT Enterprise GAC (Optional) | |
| Storage | 1 x M.2 M-Key 2280 (PCIe x4) 1 x 2.5” SATA3 SSD/HDD |
|
| Expansion | 1 x PCIe x4 (40W Max), 1 x M.2 E Key | |
| Display | ||
| Size | 15.6” wide TFT-Color LCD (16:9) | |
| Resolution Options | Option 1: 1366 x 768, 170°(H)/160°(V), 400 nits, CR: 500:1 Option 2: 1920 x 1080 (FHD), 178°(H)/178°(V), 500 nits, CR: 1000:1 |
|
| Touch Screen | Projected Capacitive Multi-Touch Light Transmission: ≥ 84% Hardness: 7H (765g/45°) Life: 50,000 touches |
|
| I/O Ports | ||
| USB | 4 x USB 3.2 Gen II | 4 x USB 3.2 Gen II 1 x ISO USB 2.0 |
| COM | 1 x RS232/422/485 1 x RS232 |
1 x ISO RS232/422/485 1 x ISO RS232 |
| LAN | 2 x RJ45 | 2 x RJ45 1 x ISO RJ45 |
| Audio/Video | 1 x Line-out, 1 x Mic-in (3.5mm jack) 1 x DisplayPort 1.4a, 1 x HDMI 2.0 |
|
| Speakers & Mic. | 2 x 2W Speakers, Integrated Mic (Bottom Side) | |
| Control Hot Keys (R to L) | Battery LED, Power, Mute, Volume +/-, Brightness +/-, LCD Backlight On/Off, Clean Me, Webcam On/Off, Function Key |
|
| Mechanical & Environmental | ||
| Cooling | Fanless Design with External Heatsink | |
| Power Input | DC 14–24V Input | |
| Power Adapter | AC 100–240V, 47–63Hz / DC 12V, 100W | |
| Temperature | Operating: 0~40℃ (IEC60068-2-78) Storage: -20~60℃ |
|
| Humidity | Operating & Storage: 10~90%, Non-condensing | |
| IP Rating / Housing | Front: IP65, Whole Unit: IPx1 Front: Flat Design – Touch (Standard), Glass (Customizable) Rear: Plastic White with Anti-Bacteria (MRSA) |
|
| Dimensions (Net) | 430 mm (H) x 300 mm (V) x 88.4 mm (T) | |
| Weight (Net) | 5 kg (w/o power adapter/battery) | |
| Mounting | VESA 75 / 100 | |
| Certifications | ||
| Compliance | CE: EN IEC 60601-1-2:2015/A1:2021 (Ed 4.1) EN 60601-1:2006/A2:2021, IEC 60601-1:2005 + A1:2012 + A2:2020 VCCI: 2016-11, Class B (PSU/Battery with PSE) FCC: Part 18 Class B UL: AAMI ES60601-1:2005 (R)2012 + A1:2012 (R)2012 + A2:2021 (By Project) cUL: CAN/CSA-C22.2 No. 60601-1:14 (By Project) ISO 14971 / IEC 62133 |
|
