Description
| Model | |
|---|---|
| WMP-105 | |
| Main System | |
| CPU / Chipset | Intel® Celeron® N3350, 1.1GHz (up to 2.4GHz) |
| Graphics | Intel® HD Graphics 500 |
| RAM | 2 × DDR3L SO-DIMM sockets, up to 8 GB |
| OS Support | Windows 10 (64-bit) – optional |
| Storage | M.2 M-key 2242 SSD (SATA 6Gb/s) |
| Expansion | 1 × Full-size Mini-PCIe (PCIe x1, USB2.0) |
| Display | |
| Size | 10.1″ |
| Resolution | 1280 × 800 |
| Colors | 16.7M |
| Viewing Angles | 170° (H) / 170° (V) |
| Brightness | 350 nits (Typ.) |
| Contrast Ratio | 800:1 (Typ.) |
| Touch Screen | |
| Type | Full flat projective capacitive |
| Light Transmission | 90% ± 3% |
| Surface Hardness | 7H (pencil, pressure: 750g / 45°) |
| I/O Ports | |
| USB | 2 × USB 3.0 |
| COM | 1 × RS232/RS422/RS485 (default RS232; RS422/RS485 via jumper) |
| LAN | 2 × RJ45 |
| Audio | Line Out, 3.5mm jack × 1, 1.5W speaker × 1 |
| Video Out | 1 × HDMI 1.4a output, 1 × VGA D-Sub |
| Control Keys | Rear Bottom: Power On/Off |
| Mechanical and Environmental | |
| Cooling | Fanless |
| Power Input | 1 × 9 ~ 36V DC-in |
| Power Adapter | External, 63W (AC 100~240V in / DC 12V out) |
| Operating Temperature | 0 ~ 50°C (IEC60068-2-78) |
| Storage Temperature | -20 ~ 60°C |
| Humidity | 10 ~ 90%, non-condensing |
| IP Rating / Housing | IP65 Front / Silver Bezel, Black Cover |
| Dimensions (Net) | 263.3 × 171 × 35.7 mm |
| Weight (Net) | 1.27 kg (approx., w/o adapter) |
| Mounting | Chassis, VESA 75×75 |
| Certification | |
| Standards | CE / FCC / VCCI Class B Canada ICES-003 CE EN60601-1-2 |
