Description
| System | |
|---|---|
| Processor |
• NX 16G: 1024-core NVIDIA Ampere GPU (25W / 100 TOPS) • NX 8G: 1024-core NVIDIA Ampere GPU (20W / 70 TOPS) • Nano 8G: 1024-core NVIDIA Ampere GPU (25W / 67 TOPS) • Nano 4G: 512-core NVIDIA Ampere GPU (25W / 34 TOPS) |
| LAN Chipset |
• GbE1: RGMII • GbE2–4: Intel LAN IC |
| System Memory | 8 GB / 16 GB LPDDR5 @ 3200 MHz |
| TPM | TPM 2.0 |
| Display | |
| HDMI | 1 × HDMI 4K (3840×2160) @ 60Hz |
| Storage | |
| M.2 | 1 × M.2 M-Key (2242/2280, PCIe x4 NVMe, Default 128GB) |
| SD | 1 × Micro SD Slot |
| SIM | 1 × External Dual Nano SIM Socket (via M.2 B-Key) |
| Expansion | |
| M.2 Slots |
• 1 × M.2 B-Key (2242/3042/3052, USB 3.2 Gen1, 4G/5G Module) • 1 × M.2 E-Key (2230, PCIe x1, USB 2.0, Wi-Fi/Bluetooth) |
| I/O | |
| CAN | CAN 2.0B |
| COM | 2 × RS-232/422/485 (switchable) |
| DIO | 8 In / 8 Out (Isolated) |
| LAN | 4 × RJ45 |
| OOB | 1 × RJ45 (Optional OOB Mgmt Module) Occupies 1 × COM & Micro USB Console Port |
| PoE | 4 × RJ45 (Optional PoE+ Module) Type 2, Max 25W per Port, Total 120W |
| USB |
• 4 × USB 3.2 Gen 2 (10 Gbps, Shared via USB 3 Hub) • 1 × Micro USB (Console) • 1 × USB Type-C (USB 2.0, for OS Flashing) |
| Others |
• 6 × Wi-Fi Antenna Holes • Power, Reset, Force Recovery Switches • 2-pin Terminal Block for Remote Power SW • CMOS Battery Cable, 4-Pin FAN Connector |
| Operating System | |
| OS | Linux Ubuntu 22.04 with JetPack 6.2 |
| Power | |
| Power Adapter |
• 12V/5A (60W) • 24V/5A (120W) – for PoE • 24V/9.2A (220W) – for PoE |
| Power Mode | AT / ATX |
| Ignition Sensing | Adjustable Power Ignition Management |
| Power Input | 9~36 VDC |
| PoE Budget |
• 12V Input: Up to 60W • 24V Input: Up to 120W |
| Connector | 3-pin Terminal Block |
| Protection | OVP, OCP, Reverse Protection |
| Environment | |
| Operating Temp |
• -20°C to 60°C (15W Mode) • -20°C to 55°C (25W Mode) |
| Storage Temp | -30°C to 85°C |
| Humidity | 10% to 95% (non-condensing) |
| Certifications |
• CE, FCC Class A • UL 62368-1 (3rd Ed.) • E-Mark (E24) • RoHS 3.0, REACH |
| Vibration | 5 Grms (5–500 Hz, 0.5 hr/axis, with SSD) |
| Shock | 50G half-sine 11ms (with SSD) |
| Physical | |
| Dimensions | 192 (W) × 140 (D) × 58 (H) mm |
| Weight | 2.8 – 3.6 kg |
| Construction | Extruded Aluminum with Heavy-Duty Metal |
| Mounting | Wall Mounting / DIN Rail (Optional) |
