Description
| Drive Bays | |
|---|---|
| External | 3.5″ × 1* 5.25″ × 3 |
| Note | *Allows one 2.5″ HDD/SSD installed without conversion bracket |
| Cooling | |
| Cooling Fan | 1 × 12 cm (82 CFM) |
| Air Filter | Yes |
| Miscellaneous | |
| LED Indicators | Power and HDD Activity |
| Control | Power Switch and System Reset Button |
| Rear Panel | Backplane Version: 1 × 9-pin D-Sub opening Motherboard Version: 5 × 9-pin D-Sub openings, 1 × 25-pin D-Sub opening |
| Environment | |
| Operating Temperature | 0 ~ 40 °C (32 ~ 104 °F) |
| Non-Operating Temperature | -20 ~ 60 °C (-4 ~ 140 °F) |
| Operating Humidity | 10 ~ 85% @ 40 °C, non-condensing |
| Non-Operating Humidity | 10 ~ 95% @ 40 °C, non-condensing |
| Vibration | Operating: 1 Grms (5 ~ 500 Hz) Non-Operating: 2 G (5 ~ 500 Hz) |
| Physical Characteristics | |
| Color / Logo | IPC-610-L: Beige / Advantech Logo IPC-611: Black / No Logo |
| Dimensions (W × H × D) | 482 × 177 × 479 mm (19″ × 7″ × 18.9″) |
| Weight | 14.5 kg (31.9 lb) / 14.2 kg (31.2 lb) |
