| System Hardware |
| CPU |
Intel® Cherry Trail Quad-core Z8350, 1.44GHz ~ 1.92GHz |
| Memory |
4GB RAM |
| Storage |
64GB |
| Camera |
| Front Camera |
2MP, Fixed Focus |
| Rear Camera |
5MP, Auto Focus |
| Audio |
| Speaker |
Single speaker, 1.2W / 8Ω |
| Microphone |
Waterproof MIC |
| Controls & Indicators |
| Buttons |
Power, Volume +/-, 1× Barcode Scanner Shortcut Key |
| LED Indicator |
Charging Indicator |
| Sensor |
G-Sensor |
| Display |
| LCD Type |
8″ TFT-LCD |
| Resolution |
1280×800 |
| Cover Glass |
Corning Gorilla Glass III, 7H hardness, 85% light transmittance |
| Luminance |
500 cd/m² (Optional: 1000 cd/m²) |
| Touchscreen |
5-Point Projected Capacitive Touchscreen, up to 10-point optional, AG+AF optional |
| Operating System |
| OS |
Windows 10 |
| I/O Interface |
| POGO Pin |
1× POGO PIN (USB + Charging) |
| USB |
1× USB Type-C (OTG + Charging), 1× USB 2.0 Type-A |
| Video Output |
1× Mini HDMI |
| Audio |
3.5mm Headphone Jack |
| DC Jack |
1× DC Jack |
| SIM Card Slot |
1× Micro SIM Card Slot |
| TF Card Slot |
1× TF Card Slot (up to 256GB) |
| Aviation Plug |
Optional 1× CAN Interface |
| Communication |
| WWAN |
Quectel EC-25EC (Europe/Middle East/Africa/Korea/Thailand) |
| LTE FDD |
B1/B3/B7/B8/B20/B28A |
| WCDMA |
B1/B8 |
| GSM |
B3/B8 |
| WiFi |
802.11a/b/g/n/ac, Dual-band (2.4GHz + 5.2GHz) |
| Bluetooth |
Bluetooth 4.0 (BLE) |
| GNSS |
U-blox GPS + BeiDou + GLONASS |
| Extended Functions |
| NFC / RFID |
Optional: NFC / HF-RFID / UHF-RFID (Choose 1) |
| Fingerprint |
Optional Fingerprint Recognition |
| Barcode Scanner |
Optional: 1D / 2D Barcode Scanner (Choose 1) |
| Power |
| Power Input |
5V DC Input, 5V/3A Power Adapter (Optional: 5–24V DC input, no built-in battery) |
| Battery |
9800mAh, 3.8V Li-Ion |
| Battery Life |
Approx. 8 hours (1080P video at 50% backlight) |
| Environment |
| Drop Resistance |
1.2m free fall to wooden floor |
| IP Rating |
Standard IP65, Optional IP67 |
| Operating Temperature |
-10℃ to 50℃ |
| Storage Temperature |
-30℃ to 70℃ (excluding batteries) |
| Certifications |
| Certifications |
CE, ROHS, UN38.3, MSDS |
| Mechanical |
| Dimensions (W×H×D) |
227 × 142.4 × 22.9 mm (Add 9.5mm with optional UHF RFID module) |
| Weight |
0.80 kg |
| Color |
Black |
| Accessories |
| Standard Accessories |
Hand strap, Type-C OTG cable, 5V/3A power adapter |
| Optional Accessories |
Docking, Vehicle bracket, Vehicle charger, Passive stylus, Type-C data cable, Vehicle charging bracket |
